Panasonic NPM-W2 Multifunctional Mounter placement machine
Product Features of Panasonic NPM-W2 Multi-Function Mounter
1. Install & inspect a complete system to achieve efficient and high-quality production
To match the actual installation requirements, you can choose high-yield or high-precision mode
2. Can correspond to larger substrates and large components
Correspondingly, on a large substrate of 750×550 mm, the component range is also expanded to L150×W25×T30mm
3. Double-track installation (select specifications) to achieve high productivity per unit area
According to the production substrate, you can choose independent mounting, alternate mounting, mixed mounting and other mounting methods
Samsuang Hanwha DECAN F2
Specifications
- Alignment
- Fly Camera, Fix Camera
- Spindle & Speed
- 2 Gantry * 10 Spindles / 80,000 CPH
- Accuracy
- ±40µm Cpk≥1.0 (0402 (01005 inch) chip) /±30µm Cpk≥1.0 (IC, Stage Vision)
- Component Range
- Fly: 0402 ~ □16 mm / Fix: ~□42 mm (Standard) / ~□55 mm (MFOV) / ~ L75 mm Connector (MFOV)
- Dimension
- L 1,430 x D 1,740 x H 1,995
Samsung Hanwha DECAN S1 mounter placement pick and place machine
Specifications
- Alignment
- Fly Camera, Fix Camera
- Spindle & Speed
- 1 Gantry * 10 Spindle / 47,000 CPH
- Accuracy
- ±28μm @ Cpk≥ 1.0 (Chip) / ±30μm @ Cpk≥ 1.0 (IC)
- Component Range
- Fly: 03015 ~ □16 mm / Fix: ~□42 mm (Standard) / ~□55 mm (MFOV) / ~ L75 mm Connector (MFOV)
- Dimension
- L 1,430 x D 1,740 x H 1,485
Samsung Hanwha High Speed Mounter DECANS2
Specifications
- Alignment
- Fly Camera, Fix Camera
- Spindle & Speed
- 2 Gantry * 10 Spindle / 92,000 CPH
- Accuracy
- ±28 μm @ Cpk ≥ 1.0 (03015 Chip) / ±25 μm @ Cpk ≥ 1.0(IC)
- Component Range
- Fly: 03015 ~ □12 mm / Fix: ~□42 mm (Standard) / ~□55 mm (MFOV) / ~ L75 mm Connector (MFOV)
- Dimension
- L 1,430 x D 1,740 x H 1,995
Samsung Hanwha HM520 mounter placement pick and place machine
Specifications
- Alignment
- Fix Camera
- Number of Spindles
- 20 spindles x 2 Gantry (Rotary Type)
- Placement Speed
- 80,000 CPH
- Placement Accuracy
- ±25 μm @ Cpk ≥ 1.0 (Chip)
- Component Range
- 0201 ~ □ 6 mm
